CobusK

Yes, it is a standard accessory with a new battery

Hi Greenfields, you are correct. The activations of the Solar Sell buttons add the selling option to the workflow. Thanks

Hi, thanks, I see your point. I've found that the description of foreign-developed UI's can sometimes be somewhat misleading. However, if one interprets the description in the manual, it explains that the 'Solar sell' option is not only relevant to the grid export function, but also necessary for the 'Zero export to load' and 'Zero export to CT'. It influences the flow logic (in combination with other settings). It should be active in both options. See the dependencies between the different workflow options in the clip below:

Keep the 'Solar sell' option selected

That is correct. See this description.

Check the wiring of the CT. It may have been swapped. You can rearrange it and see if the feedback to the grid stops.

The 'low battery' and 'restart' values will trigger a continuous alarm signal. Change the value of the restart upwards.

I would reconsider the percentages in the different time slots and activate grid charge options. If the battery DOD reaches 80% by 17:00, the Inverter will automatically switch to Grid power untill 05:00. But you'll know best what your requirements are. The inverter will always prioritize using PV to charge the batteries.

Are you intentionally selling to the grid?

It would have been very helpful if one could have access to the complete installation layout instead of addressing it piecemeal. I would recommend changing a couple of settings: Tick ' Zero export to CT'. This allows the hybrid function of the inverter to power the 'Non-essentials' as well. compared to your current setting of 'Zero export to load'

Post the current settings on Main Inverter 'SYSTEM WORK MODE' 2 (2nd Menu) This menu

I would say that is good service from Pylontech

What period of time did your previous batteries last? How is the warranty of the replacements affected?

Please note that wireless data logging will not be available, as the dongle will not be functioning. The board needs to be replaced or fixed

Hi Tokkie, it is suspicious and really too good to be true. Don't fall for it
